Ubiquiti | UC-Cast | UniFi Display Cast | Instantly transform TV display to managed digital signage
This is a 4-in 2-out HDMI matrix switch, which can switch 4 HDMI input signals to 2 HDMI displays as required. It supports up to 4096x2160@60Hz HDR resolution, with multiple switching methods (IR remote control, buttons, RS-232) to flexibly match input and output devices. HDMI outputs support auto down-scaling. Additional audio output is supported through the S/PDIF port and stereo jack. This device is a reliable, ultra-high-definition video transmission solution widely used in security monitoring, education and training, exhibition and broadcasting, command center, and other scenarios.
FEATURES
Wireless Screen Sharing: Share screens wirelessly with ease
Video Conferencing Integration: Connect seamlessly with popular conferencing apps
4K Resolution: Experience high-quality video output for immersive presentations
Cross-Platform Compatibility: Works seamlessly with various devices and operating systems
Secure Data Transfer: Ensure privacy and security during collaborative sessions
Intuitive User Interface: User-friendly setup and controls for hassle-free operation
BYOD Support: Utilize your own devices for presentations and meetings
SPECIFICATIONS
Dimensions:
Without mount: 90 x 52 x 31 mm
With mount: 92.1 x 56.3 x 35.7 mm (3.6 x 2.1 x 1.4")
Weight:
Without mount: 163 g (5.8 oz)
With mount: 183 g (6.5 oz)
Processor: Quad-core Arm Cortex-A55, 1.9 GHz
Memory:
Storage: 16 GB,
DRAM: 2 GB
Supported Power Method:
PoE: 48V DC, 0.104A (PoE Injector not included)
USB-C: 5V DC, 1A
Connectivity: 1 x GbE RJ45 port
Ambient Operating Temperature: 0 to 40°C (32 to 104°F)
Ambient Operating Humidity: 20 to 90% non-condensing
